Turck BI15-M30-AP6X-H1141 Inductive Sensor – With Increased Switching Distance
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
Turck BI15-M30-AP6X-H1141 Inductive Sensor – With Increased Switching Distance
Technical data
Type BI15-M30-AP6X-H1141
ID 46185
General data
Rated switching distance 15 mm
Mounting conditions Flush
Secured operating distance ≤ (0.81 × Sn) mm
Correction factors St37 = 1; Al = 0.3; stainless steel = 0.7;
Ms = 0.4
Repeat accuracy ≤ 2 % of full scale
Temperature drift ≤ ±10 %
Hysteresis 3…15 %
Electrical data
Operating voltage 10…30 VDC
Residual ripple ≤ 10 % Uss
DC rated operational current ≤ 200 mA
No-load current 15 mA
Residual current ≤ 0.1 mA
Isolation test voltage ≤ 0.5 kV
Short-circuit protection yes / Cyclic
Voltage drop at Ie ≤ 1.8 V
Wire breakage/Reverse polarity protection
yes / Complete
Output function 3-wire, NO contact, PNP
Insulation class ÷
Switching frequency 0.3 kHz
Mechanical data
Design Threaded barrel, M30 x 1.5
Dimensions 62 mm
