T186E W/16 | Banner
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : Banner
- Product No. : T186E W/16
- Product Type : T18 Series Sensors (DC Voltage)
- Sensing Mode : Opposed
- Range : 20 m (66 ft)
- LED : Infrared, 950nm
- Cable Length : 4.9m (16 ft)
- Supply Voltage and Current : 10 to 30 V dc (10% maximum ripple)
- Supply Protection Circuitry : Protected against reverse polarity and transient voltages
- Output Configuration :
- SPDT solid-state dc switch; Choose NPN (current sinking) or PNP (current sourcing) models
- Light Operate: N.O. output conducts when sensor sees its own (or the emitter’s) modulated light
- Dark Operate: N.C. output conducts when the sensor sees dark; the N.C. (normally closed) output may be wired as a normally open marginal signal alarm output, depending upon wiring to power supply (U.S. patent 5087838)
- Output Rating :
- 150 mA maximum (each) in standard wiring. When wired for alarm output, the total load may not exceed 150 mA.
- OFF-state leakage current: < 1 microamp at 30 V dc
- ON-state saturation voltage: < 1 V at 10 mA dc; < 1.5 V at 150 mA dc
- Output Protection Circuitry : Protected against false pulse on power-up and continuous overload or short circuit of outputs
- Operating Conditions :
- −40 °C to +70 °C (−40 °F to +158 °F)
- 90% at +50 °C maximum relative humidity (non-condensing)
- Output Response Time : 3 ms ON, 1.5 ms OFF
- Repeatability : 375 μs
- Construction :
- Housing: PBT polyester housing
- Lens: polycarbonate (opposed-mode) or acrylic (other models)
- Shipping Weight : 2 Kg
