Description
- Manufacturer : Banner
- Product No. : T186E
- Product Type : T18 Series
- Features EZ-BEAM technology, with specially designed optics and electronics for reliable sensing without adjustments on most models
- Completely epoxy-encapsulated to provide superior durability, even in harsh sensing environments; QD models rated IP69K
- Features T-style plastic housing with 18 mm threaded lens
- Uses innovative dual-indicator system to take the guesswork out of monitoring sensor performance
- Includes advanced diagnostics to warn of marginal sensing conditions or output overload (dc models)
- EZ-BEAM T18 Series: Emitter
- Range: 20 m; Input: 10-30V dc
- Output: Not applicable – No outputs
- 2 m (6.5 ft) cable
- Sensing Mode (General): Opposed
- Sensing Beam: Infrared LED
- Opposed Mode Emitter/Receiver: Emitter
- Max Sensing Range [m]: 20
- Supply Voltage: 10-30 V dc
- Delay at Power-up [ms]: 100
- Repeatability (µs): 375
- Connection: 2 m Cable
- Number of Pins: 2
- IP Rating: IP67
- NEMA Rating: NEMA 6P
- Min Op. Temperature [°C]: -40
- Max Op. Temperature [°C]: 70
- Max Op. Relative Humidity [%]: 90% @ 50°C
- Basic Housing Material: Thermoplastic
- Housing Style: Barrel
- Lens Material: Polycarbonate
- Barrel Diameter [mm]: 18
