Schneider XPSAC5121 module XPSAC – Emergency stop – 24 V AC DC

Shchneider Cabling and Interfaces, Contactors and Protection Relays, Enclosures and Accessories, HMI (Terminals and Industrial PC), Industrial Communication, Interface, Measurement and Control Relays, Measurement and Instrumentation, Motion Control and Robotics, Motor Starters and Protection Components, PLC, PAC and Dedicated Controllers, Power Supplies, Power Protection and Transformers, Process Control and Safety, Pushbuttons, Switches, Pilot Lights and Joysticks, Sensors and RFID System, Signaling Units, Software, Telemetry and Remote SCADA Systems, Variable Speed Drives and Soft Starters, Busway and Cable Management, Circuit Breakers and Switches, Contactors and Protection Relays, Electrical Car Charging, Electrical Protection and Control, Emergency Lighting, Fuse and Safety Switches, Motor Starters and Protection Components, Power Monitoring and Control, Power Quality and Power Factor Correction, Pushbuttons, Switches, Pilot Lights and Joysticks, Surge Protection and Power Conditioning, Switchboards and Enclosures etc..

Schneider

Description

Description

This XPSAC safety module monitors emergency shutdown pushbuttons and limit switches. It meets the requirements of Performance Level PL e/Category 4 conforming to standard EN/ISO 13849-1 and SILCL3 conforming to EN/IEC 61508 and EN/IEC 62061. It can be used for monitoring emergency stop circuits conforming to standards EN/ISO 13850 and EN/IEC 60204-1. 24V AC/DC supply allows direct supply via an auxiliary transformer, like ABT7 or ABL6, allowing saving at installation time. It has additional solid-state output for communication with PLCs about safety status of your process.

Specifications
Range of Product Preventa Safety automation
Product or Component Type Preventa safety module
safety module name XPSAC
safety module application For emergency stop and switch monitoring
Function of module Emergency stop
Switch monitoring
Safety level Can reach PL e/category 4 EN/ISO 13849-1
Can reach SILCL 3 EN/IEC 62061
Safety reliability data MTTFd = 210.4 years EN/ISO 13849-1
DC > 99 % EN/ISO 13849-1
PFHd = 3.56E-9 1/h EN/IEC 62061
Type of start Unmonitored
Connections – terminals Captive screw clamp terminals, 1 x 0.14…1 x 2.5 mm² flexible without cable end
Captive screw clamp terminals, 1 x 0.14…1 x 2.5 mm² solid without cable end
Captive screw clamp terminals, 1 x 0.25…1 x 1.5 mm² flexible with cable end, with bezel
Captive screw clamp terminals, 1 x 0.25…1 x 2.5 mm² flexible with cable end, without bezel
Captive screw clamp terminals, 2 x 0.14…2 x 0.75 mm² flexible without cable end
Captive screw clamp terminals, 2 x 0.14…2 x 0.75 mm² solid without cable end
Captive screw clamp terminals, 2 x 0.25…2 x 1 mm² flexible with cable end, without bezel
Captive screw clamp terminals, 2 x 0.5…2 x 1.5 mm² flexible with cable end, with double bezel
Output type Relay instantaneous opening, 3 NO, volt-free
Number of additional circuits 1 solid state output
[Us] Rated Supply Voltage 24 V AC – 20…10 %
24 V DC – 20…20 %
