Schneider iC60N – miniature circuit breaker – 2P – 6A – C curve

Shchneider Cabling and Interfaces, Contactors and Protection Relays, Enclosures and Accessories, HMI (Terminals and Industrial PC), Industrial Communication, Interface, Measurement and Control Relays, Measurement and Instrumentation, Motion Control and Robotics, Motor Starters and Protection Components, PLC, PAC and Dedicated Controllers, Power Supplies, Power Protection and Transformers, Process Control and Safety, Pushbuttons, Switches, Pilot Lights and Joysticks, Sensors and RFID System, Signaling Units, Software, Telemetry and Remote SCADA Systems, Variable Speed Drives and Soft Starters, Busway and Cable Management, Circuit Breakers and Switches, Contactors and Protection Relays, Electrical Car Charging, Electrical Protection and Control, Emergency Lighting, Fuse and Safety Switches, Motor Starters and Protection Components, Power Monitoring and Control, Power Quality and Power Factor Correction, Pushbuttons, Switches, Pilot Lights and Joysticks, Surge Protection and Power Conditioning, Switchboards and Enclosures etc..



Schneider

Description

Schneider iC60N – miniature circuit breaker – 2P – 6A – C curve

This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 6A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 20kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 4 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 85mm x (D) 78.5mm. The weight is 0.25kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C.
