Schneider ATV71HC20N4D variable speed drive ATV71 – 200kW-300HP – 480V – EMC filter-graphic terminal

Shchneider Cabling and Interfaces, Contactors and Protection Relays, Enclosures and Accessories, HMI (Terminals and Industrial PC), Industrial Communication, Interface, Measurement and Control Relays, Measurement and Instrumentation, Motion Control and Robotics, Motor Starters and Protection Components, PLC, PAC and Dedicated Controllers, Power Supplies, Power Protection and Transformers, Process Control and Safety, Pushbuttons, Switches, Pilot Lights and Joysticks, Sensors and RFID System, Signaling Units, Software, Telemetry and Remote SCADA Systems, Variable Speed Drives and Soft Starters, Busway and Cable Management, Circuit Breakers and Switches, Contactors and Protection Relays, Electrical Car Charging, Electrical Protection and Control, Emergency Lighting, Fuse and Safety Switches, Motor Starters and Protection Components, Power Monitoring and Control, Power Quality and Power Factor Correction, Pushbuttons, Switches, Pilot Lights and Joysticks, Surge Protection and Power Conditioning, Switchboards and Enclosures etc..

Schneider

Description

Schneider ATV71HC20N4D variable speed drive ATV71 – 200kW-300HP – 480V – EMC filter-graphic terminal

Specifications
Range of Product Altivar 71
Product or Component Type Variable speed drive
Product Specific Application Complex, high-power machines
Component name ATV71
Motor power kW 200 kW, 3 phase 380…480 V
Maximum Horse Power Rating 300 hp, 3 phase 380…480 V
Maximum motor cable length 328.08 ft (100 m) shielded cable
656.2 ft (200 m) unshielded cable
power supply voltage 380…480 V – 15…10 %
Phase 3 phase
Line current 286 A 480 V 3 phase 200 kW / 300 hp
357 A 380 V 3 phase 200 kW / 300 hp
EMC filter Integrated
Assembly style With heat sink
variant Reinforced version
Without DC choke
Apparent power 235 kVA 380 V 3 phase 200 kW / 300 hp
Prospective line Isc 50 kA 3 phase
Nominal output current 387 A 2.5 kHz 380 V 3 phase 200 kW / 300 hp
387 A 2.5 kHz 460 V 3 phase 200 kW / 300 hp
Maximum transient current 580 A 60 s 3 phase 200 kW / 300 hp
638 A 2 s 3 phase 200 kW / 300 hp
Output frequency 0.1…500 Hz
Nominal switching frequency 2.5 kHz
Switching frequency 2.5…8 kHz adjustable
2.5…8 kHz with derating factor
Asynchronous motor control profile Voltage/frequency ratio (2 or 5 points)
Flux vector control (FVC) with sensor (current vector)
Sensorless flux vector control (SFVC) (voltage or current vector)
ENA (Energy adaptation) system for unbalanced loads
Type of polarization No impedance Modbus
