Schneider ATV32HD15N4 variable speed drive ATV32 – 15 kw – 400 V – 3 phase – with heat sink

This Altivar 32 3-phase variable speed drive has a rated power of 15kW, and a supply voltage of 380V to 500V AC. It is designed for applications such as small conveyors, hoists, bagging / labeling machines, mixers, kneaders, textile machines, pumps, compressors, fans, wood-working and metal processing machines. It has a 180mm-wide compact form-factor, allowing for a flexible and easy installation on a mounting plate without any space between adjacent drives. It also offers a snap-lock seal, status and faults display, a jog dial navigation button and an integrated EMC filter. It offers high readability of key parameters thanks to a bright LED 4-digit display. SoMove software compatibility enables saving and transfering of configurations to spare drive, reducing maintenance downtime.

Specifications
Range of Product Altivar 32
Product or Component Type Variable speed drive
product destination Synchronous motors
Asynchronous motors
Product Specific Application Complex machines
Function Available –
Assembly style With heat sink
Component name ATV32
EMC filter Class C2 EMC filter integrated
Phase 3 phase
[Us] rated supply voltage 380…500 V – 15…10 %
Supply voltage limits 323…550 V
Supply frequency 50…60 Hz – 5…5 %
Network Frequency 47.5…63 Hz
Motor power kW 15 kW 380…480 V
Maximum Horse Power Rating 20 hp 380…480 V
