Pro-Face PFXST6500WADE HMI
Pro-face is a pioneer in HMI, providing industrial IoT solutions such as high-performance industrial computers, advanced HMIs, standard HMIs, basic HMIs and data collectors
Description
- Manufacturer : Pro-Face
- Part Number : PFXST6500WADE
- Family : HMI
- Series : ST6000 Series
- Size : 10″ Wide
- Model : PFXST6500WADE
- Global Code : PFXST6500WADE
- Product Features : 10″ DC Analog
- Display type : TFT Color LCD
- Display size : 10.1″ Wide
- Resolution : 1,024 x 600 pixels (WSVGA)
- Effective display area : W222.72 x H125.28 mm [W8.77 x H4.93 in.]
- Display colors : 16 million colors
- Backlight : White LED
- Backlight service life : 50,000 hrs. or more
- Brightness control : 16 Levels (Adjusted with touch panel or software)
- Touch panel type : Resistive Film (analog, single-touch)
- Touch panel resolution : 1,024 x 1,024
- Touch panel lifetime : 1,000,000 times or more
- Rated input voltage : 24 Vdc
- Input voltage limits : 19.2 to 28.8 Vdc
- Allowable voltage drop : 10 ms or less
- In-rush current : 30 A or less
- Grounding : Functional grounding: Grounding resistance of 100 Ω, 2mm2 (AWG 14) or thicker wire, or your country’s applicable standard. (Same for FG and SG terminals)
- Cooling method : Natural air circulation
- External dimensions : W273 x H203 x D47 mm [W10.75 x H7.99 x D1.85 in.]
- Panel cut-out dimensions : W255 x H185 mm [W10.03 x H7.28 in.] | Panel thickness area: 1.6 to 5 mm [0.06 to 0.2 in.]*2
- Weight : 1.3 kg [2.87 lb] or less
- Shipping weight : 8 Kg
