Pro-Face PFXLM4301TADAC Source Output Type
Pro-face is a pioneer in HMI, providing industrial IoT solutions such as high-performance industrial computers, advanced HMIs, standard HMIs, basic HMIs and data collectors
Description
- Manufacturer : Pro-Face
- Part Number : PFXLM4301TADAC
- Models : PFXLM4301TADAC = Source Output Type
- Resolution (pixels) : 320 x 240 (QVGA)
- Active display area (W x H) : 115.2 x 86.4 mm (4.53 x 3.40 in.)
- Display Colors : 65,536 colors
- Backlight : White LED | Non-exchangeable | LED ON / OFF control, adjustable screen saver activation time
- Touch Panel : Type = Resistive Film (analog) | Lifetime = 1 million touches or more
- Rated input voltage : 24 Vdc
- Input voltage limits : 20 to 28.8 Vdc
- Acceptable Voltage Drop : 10 ms or less at 20.4 Vdc
- Vibration immunity (operating) : IEC61131-2
- Protection structure : NEMA TYPE 4X (indoors, with panel embedded)
- Protection (front module) : IP65f -(IEC60529)
- Protection (rear module) : IP20 -(IEC60529)
- Shock immunity (operating) : IEC61131-2 15gn 11ms
- Cooling method : Natural air circulation
- Color Front module : PT404 Rear module: RAL 7032
- Material Front module : PAA+GF Rear module: PC/PBT
- Weight : 784 g (27.65 oz)
- Shipping weight : 2 Kg
