P+F Inductive sensor NBB2-8GM40-E2-V3

P+F Industrial sensors, proximity sensors, optical sensors, industrial vision, ultrasonic sensors, rotary encoders, positioning systems, tilt and acceleration sensors, industrial communications, identification systems, logic control units, connectors, power lines, sub-lines, explosion- Isolated Safety Barrier, Zener Pressure Barrier, Number Regulator, Fieldbus Device, Remote I / O Device, HART Interface Device, Surge Protection, Wireless HART, Intrinsically Safe Mobile Devices, Level Measurement Equipment, Positive Pressure Explosion Proof Equipment, HMI + visual operation terminal, electrical explosion-proof equipment, power supply equipment. etc...

Pepperl+Fuchs

Description

P+F Inductive sensor NBB2-8GM40-E2-V3

  • 2 mm flush
  • Increased operating distance
  • Extended temperature range
    -40 … +85 °C

    General specifications
    Switching function Normally open (NO)
    Output type PNP
    Rated operating distance 2 mm
    Installation flush
    Output polarity DC
    Assured operating distance 0 … 1.62 mm
    Actuating element mild steel, e. g. 1.0037, SR235JR (formerly St37-2)
    8 mm x 8 mm x 1 mm
    Reduction factor rAl 0.4
    Reduction factor rCu 0.3
    Reduction factor r304 0.75
    Reduction factor rBrass 0.45
    Output type 3-wire
    Nominal ratings
    Operating voltage 5 … 30 V
    Switching frequency 0 … 6000 Hz
    Hysteresis typ. 5%
    Reverse polarity protection reverse polarity protected
    Short-circuit protection pulsing
    Voltage drop ≤ 1.5 V
    Operating current 0 … 100 mA
    Off-state current 0 … 0.2 mA
    No-load supply current ≤ 10 mA
    Time delay before availability ≤ 100 ms
    Switching state indicator Multihole-LED, yellow
