R4348 A/1026 This Monitor is non-contact and the sensitive element is a UV photocell, which is placed away from the flame but “in sight” of the flame. The ultraviolet photosensitive tube is a special light-sensitive element, which receives ultraviolet light of 180-260 mm wavelength from the flame, while x is insensitive to light from the sun, incandescent lamps, fluorescent lamps, incandescent parts, etc. It has high sensitivity and impact. It has a high sensitivity, fast impact speed, anti-interference ability and so on.
The technical specifications of a commonly used UV photosensitive flame monitor are as follows:
R4348 A/1026 flame monitoring sensitive distance: less than 0.5m.
R4348 A/1026 fire response time: not more than 2s.
R4348 A/1026 flame out response time: not more than 3s.
R4348 A/1026 working voltage: 220V, frequency: 50Hz
R4348 A/1026 control box working environment temperature: -40 ~ 55 ℃
R4348 A/1026 sensor working environment temperature: not more than 100 ℃.
R4348 A/1026 relay contact – large load: 220V, 50BHz, inductive current 3A.
R4348 A/1026 power consumption: no more than 15V-A (excluding contact load).
