Honeywell Flame Detector C7961E1014 ,a self-checking flame detector using a solid state UV sensor to detect ultraviolet radiation in flames for supervision of gas, oil or combination gas-oil burners.
Product Specifications
| Application | Gas, Oil or other fuels |
| Dimensions (in.) | 3 3/4 in. diameter (5 1/4 in. diameter including mounting flange) x 7 7/32 in. long |
| Dimensions (mm) | 95 mm diameter (133 mm diameter including mounting flange) x 183 mm long |
| Includes | Quartz Viewing Window rated for 20 psi (138 kPa) |
| Used With | R7851C Dynamic Self-Check Amplifier |
| Weight (lb) | 2.6 lb |
| Weight (kg) | 1.2 kg |
| Comments | Detects ultraviolet radiation generated by combustion of gas, oil, or other fuels |
| Mounting | 1 in. NPT |
| Electrical Ratings | 120 Vac (-15% +10%) |
| Frequency | 50 Hz; 60 Hz |
| Approvals, Underwriters Laboratories Inc. | Component Recognized: File No. MP268 |
| Approvals, Canadian Standards Association | Certified: Pending |
| Electrical Connections | NEC Class 1 color-coded |
| Approvals, Swiss RE | Acceptable |
| Approvals, Factory Mutual | Pending |
| Ambient Temperature Range (F) | -40 F to +175 F |
| Ambient Temperature Range (C) | -40 C to +80 C |
| NEMA Rating | NEMA 4 |
| Lead Length (in.) | 96 in. |
| Lead Length (mm) | 2438 mm |
