Description

Festo NECU-S-M12G3-HX 562027 Plug

Technical Data

Based on normEN 61076-2-101 EN 61984
Certificationc UL us – Recognized (OL)
Contact durability3
Product weight17.5 g
Electrical connection3-pin A-coded M12x1 Straight plug/insulation displacement connector
DC operating voltage range0 V … 32 V
Operating voltage range AC0 V … 32 V
Current rating at 40° C4 A
Surge resistance0.8 kV
Approved cable diameter2.9 mm … 5.1 mm
Individual wire diameter≥0.1 mm
Wire diameter0.9 mm … 1.6 mm
Connection cross section0.14 mm² … 0.34 mm²
Degree of protectionIP65 IP67
Ambient temperature-25 °C … 85 °C
LABS (PWIS) conformityVDMA24364-B2-L
Note on materialsRoHS-compliant
Contamination level3
Corrosion resistance class (CRC)1 – Low corrosion stress
Housing materialPA Die-cast zinc Nickel-plated
Material of screw-type lockDie-cast zinc, nickel-plated
Seals materialFPM PUR
Material of pin contactsGold-plated
