Festo ISO cylinder DSNU-25-160-PPV-A 19250

Technical Data

Stroke160 mm
Piston diameter25 mm
Piston rod threadM10x1.25
CushioningPneumatic cushioning, adjustable at both ends
Mounting positionAny
Conforms to standardCETOP RP 52 P ISO 6432
Piston rod endExternal thread
Structural designPiston Piston rod Cylinder barrel
Position sensingFor proximity sensor
Symbol00991235
VariantsPiston rod at one end
Operating pressure0.1 MPa … 1 MPa
Operating pressure1 bar … 10 bar
Mode of operationDouble-acting
Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC)2 – Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Cleanroom classClass 6 according to ISO 14644-1
Ambient temperature-20 °C … 80 °C
Impact energy in the end positions0.3 J
Cushioning length17 mm
Theoretical force at 6 bar, retracting247.4 N
Theoretical force at 6 bar, advancing294.5 N
Moving mass at 0 mm stroke71 g
Additional moving mass per 10 mm stroke6 g
Basic weight with 0 mm stroke238 g
Additional weight per 10 mm stroke11 g
Type of mountingWith accessories
Pneumatic connectionG1/8
Note on materialsRoHS-compliant
Cover materialWrought aluminum alloy Plain anodized
Seals materialNBR TPE-U(PU)
Piston rod materialHigh-alloy stainless steel
Material of cylinder barrelHigh-alloy stainless steel
