Festo ESS-15X45-ON 189415 Vacuum suction cup

Home Festo Festo ESS-15X45-ON 189415 Vacuum suction cup

Festo ESS-15X45-ON 189415 Vacuum suction cup

Festo items cover: Control Room Solutions, Drives, High Voltage Products, Low Voltage Products and Systems, Medium Voltage Products, PLC Automation, Power Converters and Inverters, Robotics, , Transformers, Collaborative Production Management, Control Systems ,Electric Vehicle Charging Infrastructure, Enterprise Software, HVDC, Offshore Wind Connections, Power Consulting, Power Electronics, Substation Automation, Protection and Control, UPS and Power Conditioning. etc..

Festo

Description

Festo ESS-15X45-ON 189415 Vacuum suction cup
Technical Data
  • Nominal width6 mm
  • Vacuum cup size15×45 mm
  • Suction cup volume1.57 cm³
  • Connection positionTop
  • Mounting positionAny
  • Symbol00991485
  • Classification of suction cup holderSize 5
  • Suction cup shapeOval, flat
  • Operating pressure-0.095 MPa … 0 MPa
  • Operating pressure-0.95 bar … 0 bar
  • Operating pressure-13.775 psi … 0 psi
  • Nominal operating pressure-0.07 MPa
  • Nominal operating pressure-0.7 bar
  • Nominal operating pressure-10.15 psi
  • Operating mediumAtmospheric air based on ISO 8573-1:2010 [7:-:-]
  • Corrosion resistance class (CRC)1 – Low corrosion stress
  • LABS (PWIS) conformityVDMA24364-A1-L
  • For use in the food industrySee supplementary material information
  • Ambient temperature-10 °C … 70 °C
  • Holding force at nominal operating pressure32 N
  • Horizontal lateral force at nominal operating pressure43 N
  • Vertical lateral force at nominal operating pressure35 N
  • Product weight23.8 g
  • Type of mountingVia vacuum connection
  • Vacuum connectionM10
  • ColorBlack
  • Shore hardness50 +/- 5
  • Note on materialsRoHS-compliant
  • Suction cup materialNBR
