Bussmann 170M6020 fuse
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
Manufacturer : Bussmann
Part Number : 170M6020
Product Name : Eaton Bussmann Series High Speed Square Body Fuse
Model Code : FUSE 1800A 600V 3/80 AR UR INDICATOR
Type : Fuse
Application : Semiconductor, DC Common bus, DC drives, power converters/rectifiers
Amperage Rating : 1800 A
Breaking capacity : 200 kA
Fuse indicator : Top fuse status indicator
Insulated metal gripping lugs (IMGL) : No
Utilization category : aR (accompanied semiconductor protection)
Voltage type : AC
Fuse size : 3
Rated voltage AC : 600 V
Center-to-center distance of connections : 78 mm
Current type : AC
Mounting dimension : M10
Class : Class aR
Clearing (I2T) : 5250000 at 660 V
Watt losses : 165 W
Clearing loss : 165
Fuse shape : Square body, slotted center bolted tags
Pre arc (I2T) : 880000
Color : None
Interrupt rating : 200 kAIC
Connection : Blade end x blade end
Construction size : 3
Packaging type : Standard
Voltage rating : 600 Vac
Fuse type : DIN 43653 | /80 Visual indicator | Bolted tag
Fuse system (according to IEC 60269) : Other
Product Length/Depth : 168 mm
Product Height : 76 mm
Product Width : 95 mm
Product Weight : 1186 g
Shipping Weight : 2.2 Kg
