Bussmann 170M6018 fuse
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : Bussmann
- Part Number : 170M6018
- Product Name : Eaton Bussmann Series High Speed Square Body Fuse
- Model Code : FUSE 1500A 690V 3/80 AR UC
- Type : Fuse
- Application : Semiconductor, DC Common bus, DC drives, power converters/rectifiers
- Amperage Rating : 1500 A
- Breaking capacity : 200 kA
- Fuse indicator : Top fuse status indicator
- Insulated metal gripping lugs (IMGL) : No
- Utilization category : aR (accompanied semiconductor protection)
- Voltage type : AC
- Fuse size : 3
- Rated voltage AC : 690 V
- Center-to-center distance of connections : 78 mm
- Current type : AC
- Mounting dimension : M10
- Class : Class aR
- Clearing (I2T) : 3100000 at 660 V
- Watt losses : 160 W
- Clearing loss : 160
- Fuse shape : Square body, slotted center bolted tags
- Pre arc (I2T) : 460000
- Color : None
- Interrupt rating : 200 kAIC
- Connection : Blade end x blade end
- Construction size : 3
- Packaging type : Standard
- Voltage rating : 690 V (IEC), 700 V (UL)
- Fuse type : DIN 43653 | /80 Visual indicator | Bolted tag
- Fuse system (according to IEC 60269) : Other
- Product Length/Depth : 168 mm
- Product Height : 76 mm
- Product Width : 95 mm
- Product Weight : 938 g
- Shipping Weight : 2 Kg
