B&R X20DI9371 Digital Input Module
B&R is a professional industrial automation solutions provider, offering products and services for the total automation of machinery and equipment, scalable software and hardware
Description
- Manufacturer : B&R
- Product No. : X20DI9371
- Product type : X20 Digital Input Module
- I/O module: 12 digital inputs 24 VDC for 1-wire connections
- Power consumption Bus: 0.18 W
- Internal I/O: 1.75 W
- Nominal voltage: 24 VDC
- Input characteristics per EN 61131-2: Type 1
- Input voltage: 24 VDC -15% / +20%
- Input current at 24 VDC: Typ. 3.75 mA
- Input circuit: Sink
- Input filter
- Hardware: ≤100 μs
- Software: Default 1 ms, configurable between 0 and 25 ms in 0.2 ms increments
- Connection type: 1-wire connections
- Input resistance: Typ. 6.4 kΩ
- Shipping Weight : 2 Kg
