B&R X20CP1585 PLC
B&R is a professional industrial automation solutions provider, offering products and services for the total automation of machinery and equipment, scalable software and hardware
Description
- Manufacturer : B&R
- Product No. : X20CP1585
- Description : X20 PLC, Atom 333 MHz (compatible), 128 MB DDR2 RAM, 1 MB SRAM, removable application memory: CompactFlash, 1 insert slot for X20 interface modules, 2 USB interfaces, 1 RS232 interface, 1 Ethernet interface 10/100/1000BASE-T, 1 POWERLINK interface, including power supply module, 1x terminal block X20TB12, slot cover and X20 end cover plate X20AC0SR1 (right) included
- Power consumption without interface module and USB : 8.2 W
- Power consumption for X2X Link power supply : 1.42 W
- CPU and X2X Link power supply
- Input voltage : 24 VDC -15% / +20%
- Input current : Max. 1.5 A
- Fuse : Integrated, cannot be replaced
- Reverse polarity protection : Yes
- X2X Link power supply output
- Nominal output power : 7 W
- Parallel connection : Yes
- Redundant operation : Yes
- Input I/O power supply
- Input voltage : 24 VDC -15% / +20%
- Fuse : Required line fuse: Max. 10 A, slow-blow
- Output I/O power supply
- Nominal output voltage : 24 VDC
- Permissible contact load : 10 A
- Dimensions
- Width : 150 mm
- Height : 99 mm
- Depth : 85 mm
- Weight : 400 g
- Shipping Weight : 2 Kg
