B&R X20AO2632 analog output module
B&R is a professional industrial automation solutions provider, offering products and services for the total automation of machinery and equipment, scalable software and hardware
Description
- Manufacturer : B&R
- Product No. : X20AO2632
- Description : X20 analog output module, 2 outputs, ±10 V or 0 to 20 mA, 16bit converter resolution, NetTime function
- I/O module : 2 analog outputs ±10 V or 0 to 20 mA
- Power consumption
- Bus : 0.01 W
- Internal I/O : 1.1 W
- Output : ±10 V or 0 to 20 mA, via different terminal connections
- Digital converter resolution
- Voltage : ±15-bit
- Current : 15-bit
- Conversion time : 50 µs for all outputs
- Settling time for output changes over entire range : 500 μs (Rev. <H0: 1 ms)
- Switch on/off behavior : Internal enable relay for booting
- Shipping Weight : 2 Kg
