B&R X20AO2622 Module

B&R is a professional industrial automation solutions provider, offering products and services for the total automation of machinery and equipment, scalable software and hardware

B&R

Description

Manufacturer : B&R
MATERIAL NUMBER: X20AO2622
2 analog outputs
Either current or voltage signal possible
13-bit digital converter resolution
The module is equipped with 2 outputs with 13-bit (including sign) digital converter resolution. It is possible to select between the current and voltage signal using different terminals.
This module is designed for X20 6-pin terminal blocks. If needed (e.g. for logistical reasons), the 12-pin terminal block can also be used.
I/O module : 2 analog outputs ±10 V or 0 to 20 mA / 4 to 20 mA
B&R ID code : 0x1BA2
Status indicators : I/O function per channel, operating state, module status
Module run/error : Yes, using LED status indicator and software
Channel type : Yes, using software
