BES M12MI-PSC40B-BV02
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- BES M12MI-PSC40B-BV02
- DC 3-wire Inductive Global Sensors Tubular housing :M12×1
- Installation type (observe instructions in Basic Information chapter) :Flush
- Rated switching distance sn :4 mm
- Assured switching distance sa 0…3.2 mm
- Sensing distance 2X
- Supply voltage UB 12…30 V DC
- Voltage drop Ud at Ie max. 2.5 V
- Rated insulation voltage Ui (protection class) 250 V AC (?)
- Rated operating current Ie 200 mA
- Polarity reversal protected/transposition protected/short-circuit protected: Yes
- Switching frequency f max. 500 Hz
- Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20
- Approvals : CE, cULu
- 2 m PVC cable, 22 AWG
- Shipping Weight : 1 Kg
