Description

• Manufacturer : Banner
• Product No. : T18VP6UR
• Product type : U-GAGE T18U Series Sensor
• Range : Normal Resolution = 600 mm (24”), High Resolution = 300 mm (12”).
• Output : PNP (sourcing)
• Cable : Standard 2 m (6.5’) cable
• Supply Voltage : 12 to 30V dc
• Sensing Range : Normal Resolution = 600 mm (24″), High Resolution = 300 mm (12″)
• Ultrasonic Frequency : 230 KHz
• Minimum Spacing (adjacent pairs) : 50 mm for emitter-to-receiver separations of up to 150 mm. Add 10 mm of adjacent pair spacing for every 100 mm of emitter-to-receiver spacing beyond 150 mm.
• Supply Current : 50 mA (emitters); 35 mA (receivers), exclusive of output load
• Receiver Output Configuration : NPN (sinking) or PNP (sourcing), depending on model; Normally Open (NO) and Normally Closed (NC) (complementary)
• Output Rating : 150 mA max. (each output) at 25°C, derated to 100 mA at 70°C (derate ˜ 1 mA per °C). Both outputs may be used simultaneously.
• Output Protection Circuitry : Protected against overload and short circuit conditions. No false pulse upon receiver power-up
• Delay at Power-up : 100 milliseconds
• Output Response Time : Normal Resolution Mode = 2 milliseconds ON and OFF, High Resolution Mode = 1 millisecond ON and OFF.
• Shipping Weight : 2 Kg
