Banner-SMA30PEL
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- SMA30PEL
- P/N 27287
- SM30 Series: Emitter – Frequency A PBT Polyester
- Range: 150 m; Input: 10-30 V dc / 12 to 240Vac
- Output: Not applicable – No outputs
- 2 m (6.5 ft) cable
- Sensing Mode : Opposed
- Sensing Mode (General) : Opposed
- Sensing Beam : Infrared LED
- Opposed Mode Emitter/Receiver : Emitter
- Max Sensing Range (mm) : 150000
- Supply Voltage : 10-30 V dc or 12-240 V ac
- Connection : 2 m Cable
- Number of Pins : 2
- IP Rating : IP67
- NEMA Rating : NEMA 6P
- Min Op. Temp. (Celsius) : -40
- Max Op. Temp. (Celsius) : 70
- Maximum Op. Relative Humidity (%) : 90% @ 50°C
- Basic Housing Material : Thermoplastic
- Housing Style : Barrel
- Barrel Diameter (mm) : 30
- Audible Alarm : No
- Indicator : LEDs
- Remote Teach : No
- Clear Object Detection : No
- Intrinsically Safe : No
- Stainless Steel : No
- Timing (Hold/Delay) : No
- Washdown (IP68+) : No
- Water Detection : No
- Quick Disconnect Type : No QD
- Ecolab Certified : No
- Shipping Weight: 1 Kg
