Banner Series Sensors-Q45BB6DLQ5
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Banner
- Q45BB6DLQ5
- P/N 38664
- Contact a Banner Engineer About Your Application
- Q45 Series: Diffuse
- Range: 1.8 m; Input: 10-30V dc
- Output: Bipolar: 1 NPN; 1 PNP
- Quick-Disconnect Connector
- Sensing Mode (General) : Proximity
- Sensing Mode (Specific) : Diffuse
- Sensing Beam : Infrared LED
- Max Sensing Range [m] : 1.8
- Supply Voltage : 10-30 V dc
- Output Type : Bipolar (NPN & PNP)
- Operation : Light/Dark Operate
- Output response time [ms] : 2
- Delay at Power-up [ms] : 100
- Repeatability (µs) : 500
- Connection : Integral QD
- Number of Pins : 4
- IP Rating : IP67
- NEMA Rating : NEMA 6P
- Min Op. Temperature [°C] : -40
- Max Op. Temperature [°C] : 70
- Max Op. Relative Humidity [%] : 90% @ 50°C
- Basic Housing Material : Thermoplastic
- Housing Style : Rectangular
- Lens Material : Acrylic
- Adjustments : Potentiometer
- Barrel Diameter [mm] : 30
- Shipping Weight: 1 Kg
