Description

• Manufacturer: Banner

• Q12RB6RQ
• WORLD-BEAM Q12 Series: Opposed
• Range: 2 m; Input: 10-30V dc
• Output: DO (Dark Operate) Bipolar: 1 NPN; 1 PNP
• Pico (M8) Threaded Pigtail Quick-Disconnect
• WORLD-BEAM Q12 Series
• Sets a new industry standard for ultra-miniature photoelectric sensors
• Features a housing just 22 by 8 by 12 mm, with bipolar NPN/PNP outputs
• Available in opposed, fixed-field, and polarized and non-polarized retroreflective sensing modes
• Delivers powerful sensing performance in extremely confined areas
• Rated IP67 for use in the widest range of locations and applications
• Available in models with rugged, sealed housing or PFA chemical-resistant jacket
• Mounts directly on or inside manufacturing equipment, with robust metal-lined mounting holes consistently located on all models
• Uses unique overmolded design for enhanced durability and shielding
• Available in dark- or light-operate models
• Sensing Mode (General) : Opposed
• Sensing Beam Wavelength : 640
• Opposed Mode Emitter/Receiver : Receiver
• Max Sensing Range [m] : 2
• Supply Voltage : 10-30 V dc
• Output Type : Bipolar (NPN & PNP)
• Operation : Dark Operate
• Output response time [ms] : 1.3,0.7
• Delay at Power-up [ms] : 120
• Repeatability (µs) : 175
• Connection : Pigtail QD
• Number of Pins : 4
• IP Rating : IP67
• Min Op. Temperature [°C] : -20
• Max Op. Temperature [°C] : 55
• Max Op. Relative Humidity [%] : 95% @ 50°C
• Basic Housing Material : Thermoplastic
• Housing Style : Rectangular
• Lens Material : Polycarbonate
• Shipping Weight: 1 Kg
