Description

• Manufacturer: Banner
• Q45ULIU64BCR
• Housing Style : Rectangular
• Primary Housing Material : PBT
• Sensing Mode (General) : Proximity
• Sensing Mode (Detailed) : Diffuse
• Input/Output : Analog
• Max Sensing Range (mm) : 3000
• Indicator : LED(s)
• Analog Output Configuration : 0-10 V dc or 4-20 mA
• Analog Resolution/Discrete Repeatability : +/- 0.1% of sensing distance (+/- 0.5 mm min.)
• Minimum Sensing Range (mm) : 250
• Power Supply : 15-24 V dc
• Sensing Beam : Ultrasonic
• Adjustments : Teach Button, DIP Switches
• Cover Material : Acrylic
• Connection : 2 m Cable
• Quick Disconnect Type : No QD
• Number of Pins : 5
• Discrete (Switched) Outputs : N/A
• Output Protection : Protected against false pulse on power-up and continuous overload or short-circuit of outputs
• IP Rating : IP67
• NEMA Rating : NEMA 6P
• Max Operating Temperature (°C) : 70
• Min Operating Temperature (°C) : -25
• Max Operating Relative Humidity (%) : 100
• Minimum Response Time (ms) : 80
• Analog Linearity (mm) : 1% of full scale
• Barrel Diameter (mm) : N/A
• Minimum Window Size (mm) : 25
• Laser Classification : N/A
• Supply Current (exclusive of load) mA : 100 mA
• Supply Protection Circuitry : Protected against reverse polarity and transient overvoltages
• Feature: Chemical Resistant : No
• Feature: Pump-in/ Pump-out : No
• Shipping Weight : 1 Kg
