Description
- Manufacturer: Banner
- M12PFF75W30
- Housing Style : Barrel
- Primary Housing Material : Nickel-Plated Brass
- Sensing Mode (General) : Proximity
- Sensing Mode (Detailed) : Background Suppression (Fixed)
- Input/Output : Discrete
- Max Sensing Range (mm) : 75
- Outputs : PNP
- Power Supply/Supply Voltage : 10-30 V dc
- Connection : 9 m Cable
- Quick Disconnect Type : No QD
- Sensing Beam : Visible Red LED
- Operation : Light/Dark Operate
- Max Op. Temp. (°C) : 60
- Min Op. Temp. (°C) : -20
- Output response time (ms) : 0.5 on/off
- Special Feature: Intrinsically Safe : No
- Special Feature: Remote Teach : No
- Special Feature: Water Detection : No
- IP Rating : IP67, IP68
- Sensing Beam Wavelength : 680
- Laser Classification : N/A
- Delay at Power-up (ms) : 100
- Repeatability (µs) : 95
- Number of Pins : 4
- NEMA Rating : NEMA 5, 6 and 1200 PSI Washdown
- Max Op. Relative Humidity [%] : 90% @ 50°C
- Lens Material : PMMA
- Adjustments : N/A
- Barrel Diameter (mm) : 12
- Indicator : LEDs
- Opposed Mode Emitter/Receiver : N/A
- Feature: Washdown Rated : Yes
- Feature: Clear Object Detection : No
- Feature: Timing (Hold/Delay) : No
- Feature: Ecolab Certified : No
- Feature: Encapsulated : Yes
- Feature: Hazardous Area : No
- Feature: Audible : No
- Shipping Weight : 1 Kg
