Banner-LX3EQ
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- LX3EQ
- P/N 02661
- LX Series: Emitter; Standard Range
- Range: Normal 300 mm to 2 m; Input 10-30V dc
- Output: No output
- Quick-Disconnect Connector
- Max Sensing Range (mm) : 2000
- Sensing Beam : Infrared LED
- Slot Depth/Array Length (mm) : 67
- Output Type : Bipolar (NPN & PNP)
- Quick Disconnect Type : M12 (Euro)
- Connection : Pigtail QD
- Number of Pins : 5
- Supply Voltage : 10-30 V dc
- Output response time (ms) : 0.8 ON/6 OFF
- Housing Material : Metal
- Housing Style : Array
- Lens Material : Acrylic
- Remote Teach : No
- Minimum Object Detection (mm) : 9.5
- Operation : Dark Operate
- Indicator : LEDs
- Max Op. Temp. (Celsius) : 70
- Min Op. Temp. (Celsius) : -20
- Maximum Op. Relative Humidity (%) : 90% @ 50°C
- IP Rating : IP65
- Shipping Weight: 1 Kg
