Banner-K50APLPGREQ
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- K50APLPGREQ
- P/N 76284
- K50 E-Series EZ-LIGHT: 2-Color Polar Retro Sensor
- Voltage: 12-30V dc; Housing: Polycarbonate; IP67
- Range: 2 m; Input: PNP (NO); Colors: Green Red
- Euro-style Quick-Disconnect Connector
- Supply Voltage : 18-30 V dc
- Environmental Rating : IP67
- Input Type : PNP
- Housing Material : Thermoplastic
- Intensity : Standard
- Color Option 1 : Green
- Color Option 2 : Red
- Color Option 3 : Yellow
- Connection Type : Integral QD
- Number of Pins : 4
- Max Op. Temp. (Celsius) : 50
- Min Op. Temp. (Celsius) : -40
- Maximum Op. Relative Humidity (%) : 95% @ 50°C
- Input Response Time On/Off (ms) : 10
- Lens Material: Polycarbonate
- Max Current – LED Color : 100
- Function/Compatability : Standard
- Vibration and Mechanical Shock : Meets Mil. Std. 202F requirements method 201A. Also meets IEC 947-5-2; 30G 11 ms duration, half sine wave.
- Mounting Option : Base
- Size/Length [mm] : 50
- Shipping Weight: 1 Kg
