Description
- R55F
- Manufacturer: Banner
- R55 Color Mark: Glass Fiber w/ Infrared LED
- Range: Depends on Fiber used; Input: 10-30V dc
- Outputs: Bipolar NPN/PNP
- 2 m (6.5 ft) Cable
- Outstanding color contrast sensitivity; detects 16 levels of gray scale.
- Depending on beam color, reliably detects the toughest color mark contrasts,
- including 20% yellow against white.
- Fast, 50-microsecond response.
- Choose from infrared or one of four visible beam colors: red, blue, green and white.
- Fibers mount in small and otherwise inaccessible areas.
- Easy push-button programming options include Static TEACH, Static Single-Point
- TEACH, Dynamic TEACH and Remote TEACH; plus manual sensitivity adjustment.
- Non-volatile memory.
- Glass fiber models function well in harsh environments typically associated with printing processes.
- Plastic fiber models function well in applications that require repeated flexing of the fibers.
- Fibers install quickly without tools.
- Bipolar (NPN/PNP) outputs with three Delay settings (0, 20 or 40 milliseconds).
- Choice of integral cable or QD connector models.
- Mounts flat or to 35 mm DIN rail; two brackets included with sensor (one for angle mount, one for flat mount)
- Shipping Weight: 2 Kg
