Banner-CL50GRYPQ
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- CL50GRYPQ
- P/N 10017
- CL50 Column Light: 3-Color Indicator
- Voltage: 18-30Vdc; Environmental Rating: IP67
- Input: PNP; Colors: Green Red Yellow
- Euro-style Quick-Disconnect Connector
- Supply Voltage: 18-30 V dc
- Environmental Rating: IP67
- Input Type: PNP
- Housing Material: Thermoplastic
- Intensity : Standard
- Color Option 1 : Green
- Color Option 2 : Red
- Color Option 3 : Yellow
- Connection Type : Integral QD
- Number of Pins : 4
- Max Op. Temp. (Celsius) : 50
- Min Op. Temp. (Celsius) : -40
- Maximum Op. Relative Humidity (%) : 95% @ 50°C
- Input Response Time On/Off (ms) : 10
- Lens Material : Polycarbonate
- Max Current – LED Color : 100
- Function/Compatability : Standard
- Vibration and Mechanical Shock : Meets Mil. Std. 202F requirements method 201A. Also meets IEC 947-5-2; 30G 11 ms duration, half sine wave.
- Mounting Option : Base
- Size/Length [mm] : 50
- Shipping Weight : 1 Kg
