AEG Thyro-A 2A 400-170 H3 Power Controllers
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : AEG
- Thyro-A 2A 400-170 H3 is the replacement of AEG Thyristor Switch Thyro-A: 2A 400-170 H1.
- Order no : Thyro-A 2A 400-170 H3
- Product type : THYRO-A Digital Thyristor SCR Power Controllers
- 2A -Thyro-A : 2-phase version for 3-phase load in cost saving 3-phase circuit; operating mode: TAKT
- 400 – Rated Voltage …H RL3 : 400 V -15% +10% 400 V -57% combined with 24 V input
- 170 -Rated Current
- H RL3-Functional Features : Set point inputs :
- Control types : Veff / V2 eff / Ieff / I2 eff
- Load monitoring : Via an adjustable response threshold
- Limitations : Current limitation Ieff / Î VAR current peak limitation to Î = 3 x Ino
- Relay output : Exchanger, max. contact load 250 V, 6 A, 180 W, 1500 VA
- Analog output : Signal level 0(2)-10 V / 0(4)-20 mA, max. compliance voltage 10 V, Can also be used as adjustment aid
- External supply: 24 V DC/AC, connected upon demand
- Operational display : Via LEDs and relay output (exchanger, indications adjustable)
- Dimensions WxHxD(mm) : 25 x 32 x 24.1
- Approx.Weight (kg) : 8
- Shipping Weight : 11 Kg
