ADV151-P50/CCC01 | Yokogawa | Digital Input Module

Home Yokogawa ADV151-P50/CCC01 | Yokogawa | Digital Input Module

ADV151-P50/CCC01 | Yokogawa | Digital Input Module

Yokogawa Production control system, distributed control system (DCS), plant resource management system (PRM), safety instrumentation system (SIS), resource management software, process control PLC / RTU, environmental analysis instrument, industrial gas chromatograph, oxygen analyzer, laser Gas analyzer, infrared gas analyzer, gas density meter, dust detector, pH meter / ORP meter, conductivity meter, dissolved oxygen meter, near infrared spectrometer, alkalinity meter, field instrumentation, differential pressure and pressure transmitter, Flowmeters, Temperature Transmitters, Level Transmitters, Field Indicators, Valve Positioners & Converters, Field Total, Solutions, Field Wireless Products, Auxiliary Instrumentation, Solutions, Advanced Control and Prediction Platform (APC) , PLC: FA-M3V, paperless recorder, paper recorder, data monitoring and recording software, digital intelligent regulator, single loop controller, signal converter, arrester, field network equipment, power monitoring products, measuring instrument etc....



Yokogawa

Description

  • Manufacturer : Yokogawa
  • Product No. : ADV151-P50/CCC01
  • Product Type : Digital Input Module
  • ADV151 – Model : Digital Input Module (32-channel, 24 V DC, Isolated)
  • P – Suffix codes : With pushbutton input
  • 5 – Suffix codes : Without status display; with no explosion protection
  • 0 – Suffix codes : Basic type
  • CCC01 – Option codes : With Connector Cover for MIL Cable [Model:ACCC01]
  • Number of input channels : 32
  • Rated input voltage (*2) : 24 V DC (sink/source)
  • Input ON voltage : 18 to 26.4 V DC
  • Input OFF voltage : 5.0 V DC or less
  • Input current (at rated input voltage) : 4.1 mA±20 % / channel
  • Maximum allowable input voltage : 30.0 V DC
  • Functions
    – Status input : Function for detecting ON/OFF status
    – Pushbutton input : Function for counting the pushbutton edges
    – SOE input : Function for capturing the SOE data
  • Input response time : 8 ms or less (for status input)
  • Minimum ON detection time : 20 ms (for pushbutton input)
  • Maximum ON/OFF : cycle 25 Hz (for pushbutton input)
  • Maximum current consumption : 500 mA (5 V DC)
  • Weight : 0.3 kg
  • Shipping Weight : 2 kg
