2866776 QUINT-PS/1AC/24DC/20 | PHOENIX | Power Supply Unit
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Phoenix
- Product Number: 2866776
- Product Type: Power Supply Unit
- Nominal input voltage range: 100 V AC … 240 V AC
- Input voltage range: 100 V AC … 240 V AC -15 % … +10 %
- Derating IStat. Boost: < 100 V AC (1 %/V)
- Input voltage range AC: 85 V AC … 264 V AC
- Input voltage range DC: 90 V DC … 350 V DC
- Electric strength, max.: 300 V AC
- Typical national grid voltage: 120 V AC, 230 V AC
- Voltage type of supply voltage: AC
- Inrush current: < 20 A
- Inrush current integral (I2t): < 3.2 A2s
- Inrush current limitation: 20 A
- AC frequency range: 45 Hz … 65 Hz
- Frequency range DC: 0 Hz
- Mains buffering time: > 32 ms (120 V AC), > 32 ms (230 V AC)
- Current consumption: 7 A (100 V AC), 5.8 A (120 V AC), 3 A (230 V AC), 3.1 A (240 V AC)
- Nominal power consumption: 569 VA
- Protective circuit: Transient surge protection; Varistor
- Power factor (cos phi): 0.89
- Typical response time: < 0.6 s
- Input fuse: 12 A (slow-blow, internal)
- Permissible backup fuse: B10 B16 AC:
- Permissible DC backup fuse: DC: Connect a suitable fuse upstream
- Recommended breaker for input protection: 10 A … 16 A (Characteristics B, C, D, K)
- Discharge current to PE: < 3.5 mA
- Shipping Weight: 5 kg
