2866695 QUINT-PS/1AC/48DC/20 | PHOENIX | Power Supply Unit

This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..

Phoenix

Description

Manufacturer: Phoenix
Product Number: 2866695
Product Type: Power Supply Unit
Nominal input voltage range: 100 V AC … 240 V AC, 120 V DC … 300 V DC (UL 508: = 250 V DC)
Input voltage range: 85 V AC … 264 V AC, 90 V DC … 300 V DC (UL 508: = 250 V DC)
Input voltage range AC: 85 V AC … 264 V AC
Input voltage range DC: 90 V DC … 300 V DC (UL 508: = 250 V DC)
Electric strength, max.: 300 V AC
Voltage type of supply voltage: AC/DC
Inrush current: < 15 A (typical)
Inrush current integral (I2t): < 1.6 A2s
AC frequency range: 45 Hz … 65 Hz
Frequency range DC: 0 Hz
Mains buffering time: typ. 20 ms (120 V AC), typ. 22 ms (230 V AC)
Current consumption: 8.7 A (120 V AC), 4.5 A (230 V AC), 9.4 A (110 V DC), 4.6 A (220 V DC)
Nominal power consumption: 1046 VA
Protective circuit: Transient surge protection; Varistor
Typical response time: < 0.65 s
Input fuse: 20 A (fast blow, internal)
Permissible backup fuse: B16 B25 AC:
Permissible DC backup fuse: DC: Connect a suitable fuse upstream
Recommended breaker for input protection: 6 A … 16 A (AC: Characteristics B, C, D, K)
Discharge current to PE: < 3.5 mA
Shipping Weight: 5 kg
