2866239 | PHOENIX | QUINT-DC-UPS/24DC/20 | Uninterruptible Power Supply
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : PHOENIX
- Part Number : 2866239
- QUINT-DC-UPS/24DC/20 | Uninterruptible Power Supply Unit for Universal Use
- Input Data :
- Nominal input voltage : 24 V DC
- Input voltage range : 22.5 – 30 V DC
- Buffer time : Can be configured = 0.5; 1; 2; 3; 5; 10;15; 20; 30; continuous
- Input fuse : Internal, 25 A
- Output Data :
- Can be connected in parallel (battery module) : Yes, to increase the buffer time
- Output Data in Normal Operation :
- Nominal output voltage : 24 V DC
- Output voltage : Uin
- Output current : 20 A
- Current limit : None
- Overload fuse : Internal, 25 A
- General Data :
- Insulation voltage :
-
- Input/output to housing : 1 kV AC type test | 1 kV AC routine test
- Mounting position :
- On a horizontal 35 mm (1.378 in.) DIN rail
- EN 60 715
- 1 kV/1 kV
- Degree of protection : IP20
- Class of protection : II
- MTBF : According to IEC 1709 (SN 29 500) = > 500,000 h
- Housing version : AluNox (AlMg1), closed
- Dimensions (W x H x D) default upon delivery : (66 x 130 x125 mm [2.598 x 5.118 x 4.921 in.])
- Dimensions (W x H x D) rotated 90°: (122 x 130 x 69 mm [4.803 x 5.118 x 2.717 in.])
- Weight : 0.8 kg
- Shipping Weight : 2 Kg
