2320924 QUINT-PS/3AC/24DC/20/CO | PHOENIX | Power supply
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Phoenix
- Product Number: 2320924
- Product Type: Power supply, with protective coating
- Nominal input voltage range: 3x 400 V AC … 500 V AC
- Input voltage range: 3x 320 V AC … 575 V AC, 2x 360 V AC … 575 V AC, 450 V DC … 800 V DC
- Voltage type of supply voltage: AC/DC
- Inrush current: < 20 A (typical)
- Inrush current integral (I2t): < 3.2 A2s
- AC frequency range: 45 Hz … 65 Hz
- Frequency range DC: 0 Hz
- Mains buffering time: typ. 28 ms (400 V AC), typ. 43 ms (500 V AC)
- Current consumption: 3x 1.6 A (400 V AC), 3x 1.3 A (500 V AC), 0.9 A (600 V DC)
- Nominal power consumption: 783 VA
- Protective circuit: Transient surge protection; Varistor, gas-filled surge arrester
- Typical response time: < 0.16 s
- Permissible backup fuse: B6 B10 B16
- Permissible DC backup fuse: DC: Connect a suitable fuse upstream
- Recommended breaker for input protection: 6 A … 16 A (AC: Characteristics B, C, D, K)
- Discharge current to PE: < 3.5 mA
- Shipping weight: 3 kg
