170M6060 | Bussmann | Eaton Bussmann Series High Speed Square Body Fuse
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : Bussmann
- Part Number : 170M6060
- Product Name : Eaton Bussmann Series High Speed Square Body Fuse
- Type : Fuse
- Application : Semiconductor, DC Common bus, DC drives, power converters/rectifiers
- Amperage Rating : 630 A
- Breaking capacity : 200 kA
- Fuse indicator : Top fuse status indicator
- Insulated metal gripping lugs (IMGL) : No
- Utilization category : aR (accompanied semiconductor protection)
- Voltage type : AC
- Fuse size : 3
- Rated voltage AC : 690 V
- Center-to-center distance of connections : 78 mm
- Current type : AC
- Mounting dimension : M10
- Class : Class aR
- Clearing (I2T) : 210000 at 660 V
- Watt losses : 105 W
- Clearing loss : 105
- Fuse shape : Square body, slotted center bolted tags
- Pre arc (I2T) : 31000
- Color : None
- Interrupt rating : 200 kAIC
- Connection : Blade end x blade end
- Construction size : 3
- Packaging type : Standard
- Voltage rating : 690 V (IEC), 700 V (UL)
- Fuse type : DIN 43653 | TN/80 Type T Indicator for Micro
- Fuse system (according to IEC 60269) : Other
- Product Length/Depth : 168 mm
- Product Height : 76 mm
- Product Width : 95 mm
- Product Weight : 935 g
- Shipping Weight : 2 Kg
