170M5668 | Bussmann | Eaton Bussmann Series High Speed Square Body Fuse
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : Bussmann
- Part Number : 170M5668
- Product Name : Eaton Bussmann Series High Speed Square Body Fuse
- Model Code : FUSE 1250A 600V 2FKE/90 AR UC
- Type : Fuse
- Application : Semiconductor, DC Common bus, DC drives, power
- converters/rectifiers
- Amperage Rating : 1250 A
- Breaking capacity : 200 kA
- Fuse indicator : Centre fuse status indicator
- Insulated metal gripping lugs (IMGL) : No
- Utilization category : aR (accompanied semiconductor protection)
- Voltage type : AC
- Fuse size : 2
- Rated voltage AC : 600 V
- Center-to-center distance of connections : 90.3 mm
- Current type : AC
- Mounting dimension : M12
- Class : Class aR
- Clearing (I2T) : 2400000 at 660 V
- Watt losses : 120 W
- Fuse shape : Square body, center bolted tags
- Pre arc (I2T) : 365000
- Color : None
- Interrupt rating : 200 kAIC
- Fitted with : Type K Indicator for micro
- Connection : Blade end x blade end
- Construction size : 2
- Packaging type : Standard
- Voltage rating : 600 V
- Fuse type : US Style | FKE/Type K indicator for micro | Bolted tag
- Fuse system (according to IEC 60269) : Other
- Product Length/Depth : 286 mm
- Product Height : 66 mm
- Product Width : 165 mm
- Product Weight : 318 g
- Shipping Weight : 1.5 Kg
